Laboratory Incubator-CLN-53

Laboratory Incubator – CLN-53

Company – Pol-Eko (Poland)

Product Code: 042827032026

Standard equipment CLN 53

• temperature range + 5°C above ambient temperature … + 100°C
• chamber volume 83 liters
• working capacity 55 liters
• quality control protocol at + 37°C
• instruction manual in English and menu in various languages
• over temperature protection 2.0 class (Smart), 3.1 class (Smart PRO) according to DIN 12880
• open door alarm
• air-flap Ø40 mm
• LAN port and USB port
• access port to enter an external sensor (Ø30 mm) on the left side of the unit
• door lock
• Stainless steel wire shelf (INOX)
• double doors (external full, internal glass)
• Wi-Fi communication (only Smart PRO)
• LAN cable (only Smart PRO)
• LabDesk software for, inter alia, downloading data to computer (only Smart Pro, for Smart version – optional)
• available controllers: Smart lub Smart PRO

TECHNICAL DATA
air convection	natural
chamber capacity [l]	83
working capacity [l]	55
controller	microprocessor PID
display	4,3″ full colour touch screen
TEMPERATURE
temperature range [°C]	5°C above ambient temperature … +100°C
temperature resolution every … [°C]	0,1
temperature fluctuation at 37°C [+/-°C]*	0,2
temperature variation at 37°C [+/-°C]*	0,7
temperature protection	class 2.0 to DIN 12880 / class 3.1 (option)
CHAMBER
door type	double(5) / door with viewing window (option)
interior
Smart	acid-proof stainless steel to DIN 1.4301
IG Smart	acid-proof stainless steel to DIN 1.4301
housing
Smart	powder coated sheet
IG Smart	stainless steel linen finish
overall dims [mm] /1/
width A	600
height B	710
depth C	620
internal dims [mm]
width D	400
height E	390
depth F	350
shelves (standard | max)	2 | 5
max shelf workload [kg] /2/	25
– reinforced shelf version (PW) [kg] /3/	50
max unit workload [kg]	40
– reinforced unit version (W) [kg] /4/	80
weight [kg]	50
ELECTRICAL PARAMETERS
voltage	230V 50/60Hz
nominal power [W]	500
warranty	24 months
manufacturer	POL-EKO®

all the above technical data refer to standard units (without optional accessories)
* – fluctuation measured in centre of the chamber; in space, variation (K) calculated for chamber as:
K= +/- (T average max. – T average min. ) / 2
** – other power supplies on request
1 – depth doesn’t include 50 mm of power cable, the width does not include the 20 mm of rubber plug
2 – on uniformly loaded surface
3 – reinforced shelf
4 – additional internal glass door
